Some of my libraries, such as Package_QFP, are not appearing in the Footprint library browser, but they do appear in the same directory as other libraries that are working correctly. In particular, I wanted to place an ATMEGA328PB, so I added it to the schematic, and it referenced footprint “Package_QFP:TQFP-32_7x7mm_P0.8mm”. Download Protel 99se Free Download - best software for Windows. Protel PCB: Protel schematic Pcb (printed circuit board) design 1.5 is a great designing.īut when I try to browse to that footprint using the viewer, it’s not found. The file is there, in C:\Program Files\KiCad\share\kicad\modules\Package_QFP.pretty\TQFP-32_7x7mm_P0.8mm.kicad_mod but it doesn’t show up when I browse footprints. I’m missing a lot of others as well! Comparing the footprint folders shown in the Footprint Editor vs. project protel99se Hi Click on the schematic component name in the library list that you want to add the footprint to, click on edit and when the editor opens, click on description, type in the footprint reference from the footprint library in the box and save the modified library. my kicad/modules directory, a TON are missing. This is a brand new install, not sure what’s going on. I know it can see the other packages, because if I browse to a similar footprint called “Housings_QFP:TQFP-32_7x7mm_Pitch0.8mm” it works fine. The Housings_QFP is in the same directory as the Package_QFP, so I don’t know why it’s seen, but Package is not.
